| Typ | Nennvol.
l | Temperatur | Temperaturkonstanz | Max. Anzahl Einschübe | Abmessung außen
(BxTxH) | Abmessungen
innen (BxTxH) | Gewicht
kg | Nennleist.
kW | Steckertyp | Stromversorgung | Menge
pro VE | Bestell Nr. | |
|---|
| BD 56 | 57 | RT+5 ... 100 °C | ±0,1 K (37 °C) | 4 | 560 x 565 x 625 mm | 360 x 380 x 420 mm | 39,0 | 0,3 | EU | 230 V, 50/60 Hz | 1 | 6.280 269 |  | | BD 56UL | 57 | RT+5 ... 100 °C | ±0,1 K (37 °C) | 4 | 560 x 565 x 625 mm | 360 x 380 x 420 mm | 39,0 | 0,3 | US | 120 V, 60 Hz | 1 | 4.705 500 | | | BD 115 | 112 | RT+5 ... 100 °C | ±0,1 K (37 °C) | 5 | 710 x 605 x 705 mm | 510 x 420 x 530 mm | 54,0 | 0,35 | EU | 230 V, 50/60 Hz | 1 | 6.280 290 | | | BD 115UL | 112 | RT+5 ... 100 °C | ±0,1 K (37 °C) | 5 | 710 x 605 x 705 mm | 510 x 420 x 530 mm | 54,0 | 0,35 | US | 120 V, 60 Hz | 1 | 4.705 501 | | | BD 260 | 253 | RT+5 ... 100 °C | ±0,2 K (37 °C) | 8 | 810 x 760 x 940 mm | 610 x 545 x 760 mm | 85,0 | 0,85 | EU | 230 V, 50/60 Hz | 1 | 6.280 291 | | | BD 260UL | 253 | RT+5 ... 100 °C | ±0,2 K (37 °C) | 8 | 810 x 760 x 940 mm | 610 x 545 x 760 mm | 85,0 | 0,95 | US | 120 V, 60 Hz | 1 | 4.705 502 | | | BD 720 | 737 | RT+5 ... 100 °C | ±0,1 K (37 °C) | 16 | 1.165 x 870 x 1.590 mm | 960 x 600 x 1.280 mm | 169,0 | 1,65 | EU | 230 V, 50/60 Hz | 1 | 6.274 532 | | | BD 720UL | 737 | RT+5 ... 100 °C | ±0,1 K (37 °C) | 16 | 1.165 x 870 x 1.590 mm | 960 x 600 x 1.280 mm | 169,0 | 1,75 | US | 240 V, 50/60 Hz | 1 | 4.705 504 | |
|
