| Typ | Nennvol.
l | Temperatur | Temperaturkonstanz | Max. Anzahl Einschübe | Abmessung außen
(BxTxH) | Abmessungen
innen (BxTxH) | Gewicht
kg | Nennleist.
kW | Steckertyp | Stromversorgung | Menge
pro VE | Bestell Nr. | |
|---|
| KB ECO 240 | 247 | 0 ... 70 °C | ±0,1 K (37 °C) | 9 | 925 x 796 x 1.461 mm | 650 x 485 x 785 mm | 152 | 0,9 | EU | 230 V, 50/60 Hz | 1 | 4.685 489 |  | | KB ECO 240UL | 247 | 0 ... 70 °C | ±0,1 K (37 °C) | 9 | 925 x 796 x 1.461 mm | 650 x 485 x 785 mm | 152 | 0,9 | US | 120 V, 50/60 Hz | 1 | 4.685 492 | | | KB ECO 400 | 400 | 0 ... 70 °C | ±0,1 K (37 °C) | 15 | 925 x 796 x 1.946 mm | 650 x 485 x 1.268 mm | 196 | 1,2 | EU | 230 V, 50/60 Hz | 1 | 4.687 513 | | | KB ECO 400UL | 400 | 0 ... 70 °C | ±0,1 K (37 °C) | 15 | 925 x 796 x 1.946 mm | 650 x 485 x 1.268 mm | 196 | 1,2 | US | 120 V, 50/60 Hz | 1 | 4.687 512 | | | KB ECO 720 | 700 | 0 ... 70 °C | ±0,1 K (37 °C) | 15 | 1.250 x 885 x 1.925 mm | 973 x 576 x 1.250 mm | 272 | 1,3 | EU | 230 V, 50/60 Hz | 1 | 4.685 490 | | | KB ECO 720UL | 700 | 0 ... 70 °C | ±0,1 K (37 °C) | 15 | 1.250 x 885 x 1.925 mm | 973 x 576 x 1.250 mm | 272 | 1,3 | US | 120 V, 50/60 Hz | 1 | 4.685 493 | | | KB ECO 1020 | 1020 | 0 ... 70 °C | ±0,1 K (37 °C) | 15 | 1.250 x 1.149 x 1.925 mm | 973 x 836 x 1.250 mm | 327 | 1,3 | EU | 230 V, 50/60 Hz | 1 | 4.685 491 | | | KB ECO 1020UL | 1020 | 0 ... 70 °C | ±0,1 K (37 °C) | 15 | 1.250 x 1.149 x 1.925 mm | 973 x 836 x 1.250 mm | 327 | 1,3 | US | 120 V, 50/60 Hz | 1 | 4.685 494 | |
|
